Features
- Direct collaboration with Cory Wong for optimized sound and feel
- Adjustable wah with three frequency ranges (WARM, CLASSIC) to suit all styles
- 4-in-1 function: Volume, Wah, Expression, and Volume/Wah combination
- Two-color status LED: blue for Wah mode, green for Volume mode
- Cory's custom volume curve for smooth, musical transitions
- True Bypass function and active design for lossless signal
- Dedicated tuner and expression outputs for more connections
- Operates on 9V DC power or 9V battery
Specifications
- Pot resistance (EXP OUT) : 10 kΩ
- Input impedance : 1 MΩ
- Output impedance : 100 Ω
- Wah Ranges (TONE Selector) :
• WARM — 290 Hz to 1.4 kHz
• CLASSIC — 360 Hz to 1.8 kHz - Consumption : max 30 mA
- Dimensions : 81 × 162 × 51 mm
- Weight : 512 g
Downloads
Download the user manual
