Features
- Second-generation amp modeler and multi-effects processor in a compact, pedalboard-compatible format
- Integrates perfectly into any pedalboard when used as a single effect
- Enhanced Ampero sound thanks to a more powerful tri-core DSP platform and ESS® Sabre® AD/DA converters
- Advanced CDCM HD & FIRE modeling system for high-end tonal expressiveness and impressive playing realism
- 24-bit signal processing with a dynamic range of up to 127 dB*
- Dynamic 4" touchscreen (800 x 480) with new intuitive user interface
- Highly customizable dual effects chain with flexible serial/parallel routing
- Add any effect module into the chain
- Stereo inputs/outputs + stereo effects loop for maximum flexibility
- Up to 12 simultaneous effects modules
- Over 400 effects available in the updated library
CDCM HD & FIRE modeling including:
- 87 modeled amps
- 68 speakers
- New speaker mic algorithm, based on real studio data
- New preamps
- Independent power section simulation
- More than 100 legendary pedals
- Over 60 original Hotone effects (overdrive, dynamics, filters, modulations, delays, reverbs, etc.)
- Dedicated IR charger compatible with third-party IRs, up to 50 user IRs
- 20 Celestion® Impulse Responses Included – Powered by Celestion® Digital
- Supports up to 2048 IR points for better sound resolution
- USB port for firmware updates, effects management and IR via Win/Mac software
- 8-in/8-out USB audio interface with Reamp function
- Acoustic effects and presets from the Ampero range
- Ampero type input mode selector
- 300 presets (100 banks x 3 patches)
- Built-in stereo looper with 60 seconds of recording + undo/redo function
- 3 assignable footswitches with LED rings
- Customizable main display with color themes
- Authentic stereo audio processing
- Full MIDI connectivity + EXP/CTRL input for external controllers
- Lightweight, robust, stage-ready aluminum chassis
- 9–18V DC power supply (center negative)
Specifications
Audio Processing
- 24-bit / 44.1kHz digital processor
- Frequency response: 20Hz – 20kHz ± 1dB
- Max dynamic range: 127 dB (D/A)
Effects & Patches
- 460 built-in effects (incl. global EQ)
- Up to 12 simultaneous effects
- 16 effects modules available
- 300 user patches
- 60 Second Stereo Looper
Entrances
- 2 x 6.35 mm TS instrument jacks with mode selection
- 1 x 3.5mm stereo mini-jack (Aux In)
- 1 x 6.35 mm TRS jack for expression pedal or footswitch (EXP/CTRL)
- 1 x 6.35 mm TRS jack FX Loop Return
- 1 x MIDI Input (5-pin DIN)
Exits
- 2 x 6.35mm TRS jack balanced stereo outputs
- 1 x 6.35 mm TRS jack FX Loop Send
- 1 x 3.5 mm stereo mini-jack headphone output
- 1 x MIDI output (5-pin DIN)
Impedances
- Input: E.GT 1MΩ / A.GT 4.7MΩ / LINE 10kΩ
- FX Loop Return: 100kΩ / Aux In: 10kΩ
- Output: 1kΩ / FX Loop Send: 1kΩ / Headphones: 47Ω
Audio levels
- Input: -17.78 dBu (nominal) / 14.5 dBu (max)
- FX Return: same
- Aux In: -17.78 dBu (nominal) / 20 dBu (max)
- Output: -11.76 dBu (nominal) / 26.25 dBu (max)
- FX Send: -17.78 dBu (nominal) / 14.5 dBu (max)
- Headphones: -7.4 dBu (nominal) / 18.3 dBu (max)
Screen & Connectivity
- 4" dynamic color touchscreen (800 × 480)
- USB-C port (USB Audio 2.0, USB 2.0 compatible)
IR / Impulse Responses
- Supports 24-bit / 44.1kHz mono WAV files
- 1024 and 2048 points, up to 50 user IRs
Power & Dimensions
- 9–18V DC center negative, 800mA max
- Dimensions: 185 × 145 × 58 mm
- Weight: 1.05 kg
