Features
- True Bypass for a pure, unadulterated signal
- Wider format for better ergonomics under the foot
- Integrated status LED indicating real-time pedal position
- 4 functions in 1: volume, wah, combined volume/wah, expression
- Wah sound inspired by legendary vocal models
- Q (filter range) and WARM/CLASSIC (frequency range) settings for more expressive wah
- Active volume circuit ensuring lossless sound
- Separate outputs for tuner and expression pedal: more connection flexibility
- 9V DC power supply or compatible 9V battery
Specifications
- Potentiometer resistance (EXP output): 10 kΩ
- Input impedance: 1 MΩ
- Output impedance: 100 Ω
- Wah frequency range:
WARM: 290 Hz – 1.4 kHz
CLASSIC: 360 Hz – 1.8 kHz - Consumption: max. 30 mA
- Dimensions: 81mm (W) × 162mm (D) × 51mm (H)
- Weight: 500 g
Downloads
Download the user manual
